Systemboardcomponents
Thefollowingillustrationshowsthecomponentlocationsonthesystemboard.
30
Figure15.Systemboardcomponents
1SATAconnector(opticaldrive)2Coin-cellbattery
3SATAconnector1(ports4–7)4SATAconnector0(ports0–3)
5Frontpanelconnector16Frontpanelconnector2
7SDmoduleconnector
8Risercardassembly1slot
9TSMPremiummoduleconnector
10TPMconnector
11PCIeslot
12Risercardassembly2slot
13RAIDupgradekeyconnector14Powersupplyconnector2
15Powersupplyconnector116Intrusionswitchconnector
17Backplanepowerconnector218Backplanepowerconnector1
19Systemfan6connector20Microprocessor2memoryslots(4)
21Systemfan5connector
22Microprocessor2socket
23Systemfan4connector24Microprocessor2memoryslots(4)
25Microprocessor1memoryslots(4)26Systemfan3connector
27Systemfan2connector
28Microprocessor1socket
29Systemfan1connector30Microprocessor1memoryslots(4)
1SATAconnector(opticaldrive)
Usedtoconnectthesignalcableoftheslimopticaldrive.
