Backplaneforeight2.5-inchdrives
Thefollowingillustrationsshowtheslotsandconnectorsonthebackplaneforuptoeight2.5-inchdrives.
Figure13.Frontviewofthebackplanefor2.5-inchdrives
Figure14.Rearviewofthebackplanefor2.5-inchdrives
0-7Slot0-slot7
Usedtoconnect2.5-inchdrives.
810-pinpowerconnector
Usedtoconnecttothebackplanepowerconnectoronthesystemboardtoprovidepowertothebackplane.
9Mini-SASports4-7
Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive4toharddiskdrive7.
10Mini-SASports0-3
Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive0toharddiskdrive3.
30ThinkServerRD350UserGuideandHardwareMaintenanceManual
