Backplanefor3.5-inchdrives
Thefollowingillustrationsshowtheslotsandconnectorsonthebackplanefor3.5-inchdrives.
Figure11.Frontviewofthebackplanefor3.5-inchdrives
Figure12.Rearviewofthebackplanefor3.5-inchdrives
0-3Slot0-slot3
Usedtoconnect3.5-inchdrives.
410-pinpowerconnector
Usedtoconnecttothebackplanepowerconnectoronthesystemboardtoprovidepowertothebackplane.
5Opticaldrivepowerconnector
Usedtoconnectthepowercablefortheslimopticaldrive.
6Mini-SASports0-3
Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive0toharddiskdrive3.
Chapter3.Productoverview29
