16Intrusionswitchconnector
Usedtoconnecttoanintrusionswitch.
1718Backplanepowerconnector
Usedtoconnecttothe10-pinpowerconnectoronthebackplane.
192123262729Systemfanconnector
Usedtoconnectasystemfan.
20242530Memoryslots
Thereare16memoryslotsonthesystemboard.Fordetailedinformation,see“Memorymoduleinstallation
rules”onpage60.
22Microprocessor2socket
28Microprocessor1socket
Iftheserverhastwomicroprocessors,eachofthemicroprocessorissecuredinthemicroprocessorsocket
onthesystemboardandaheatsinkisinstalledabovethemicroprocessortoprovidecooling.Iftheserver
hasonlyonemicroprocessor,themicroprocessorsocket2isprotectedbyamicroprocessorsocketcover.
Systemboardjumpers
Thefollowingillustrationshowsthejumpersonthesystemboardofyourserver.
Figure16.Systemboardjumpers
1Jumpercapstorage
2BIOSrecoveryjumper
3BIOSdefaultsettingsjumper4Clearpasswordjumper
Chapter3.Productoverview33
