8.PositiontheSDmoduleonthesystemboard.Ensurethattheplasticpinsonthesystemboardpass
throughthecorrespondingholesintheSDmodule.Then,presstheSDmoduledownwardsothat
itissecuredbythelatch
1.
Figure36.InstallingtheSDmodule
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage131.
RemovingtheSDmodule
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage53.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:UseanydocumentationthatcomeswiththeSDmoduleandfollowthoseinstructionsinadditionto
theinstructionsinthistopic.
ToremovetheSDmodule,dothefollowing:
1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
2.Prepareyourserver.See“Removingorextendingtheserverfromtherackcabinet”onpage55.
3.Removetheservercover.See“Removingtheservercover”onpage55.
4.Removetherisercardassembly1.See“Replacingtherisercardassembly”onpage122.
5.LocatetheSDmodule.See“Servercomponents”onpage23.
Chapter6.Replacinghardware77
