1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
2.Prepareyourserver.See“Removingorextendingtheserverfromtherackcabinet”onpage65.
3.Removetheservercover.See“Removingtheservercover”onpage65.
4.Removetherisercardassembly1.See“Replacingtherisercard”onpage81.
5.LocatetheSDmoduleconnectoronthesystemboard.See“Systemboardcomponents”onpage
41
.RemoveanypartsanddisconnectanycablesthatmightimpedeyouraccesstotheSDmodule
connector.
6.Touchthestatic-protectivepackagethatcontainstheSDmoduletoanyunpaintedsurfaceonthe
outsideoftheserver.Then,taketheSDmoduleoutofthepackage.
Note:CarefullyhandletheSDmodulebyitsedges.
7.InserttheSDcardintotheSDcardslot.ThecardmightstopbeforeitiscompletelyinstalledintotheSD
module.Ensurethatyouinsertthecardfirmlyuntilyouhearaclick.
8.PositiontheSDmoduleonthesystemboardsothattheplasticpinsonthelatchandonthesystem
boardpassthroughthecorrespondingholesintheSDmodule.Then,presstheSDmoduledownward
sothatitisconnectedtotheSDmoduleconnectoronthesystemboardandissecuredbythelatch.
Figure84.InstallingtheSDmodule
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage178
.
RemovingtheSDmodule
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage63.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•IfyouremovetheSDmodule,youcannotinstallSDcardsintoyourserverforstorage.
•UseanydocumentationthatcomeswiththeSDmoduleandfollowthoseinstructionsinadditionto
theinstructionsinthistopic.
Chapter6.Replacinghardware115
