InstallingtheTSMpremiummodule
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage63.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•UseanydocumentationthatcomeswiththeTSMpremiummoduleandfollowthoseinstructionsin
additiontotheinstructionsinthistopic.
•Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationinthistopic.
ToinstalltheTSMpremiummodule,dothefollowing:
1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
2.Prepareyourserver.See“Removingorextendingtheserverfromtherackcabinet”onpage65.
3.Removetheservercover.See“Removingtheservercover”onpage65.
4.Removetherisercardassembly2.See“Replacingtherisercard”onpage81.
5.Touchthestatic-protectivepackagethatcontainstheTSMpremiummoduletoanyunpaintedsurface
ontheoutsideoftheserver.Then,taketheTSMpremiummoduleoutofthepackage.
6.LocatetheTSMPremiumconnectoronthesystemboardandtheninserttheTSMpremiummoduleinto
theTSMPremiumconnector.
Note:EnsurethattheTSMpremiummoduleissecurelyseatedonthesystemboard.
Figure86.InstallingtheTSMpremiummodule
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage178
.Then,
refertotheThinkServerSystemManagerUserGuide,whichisavailablefordownloadat
http://www.lenovo.com/UserManuals,formoreinformationaboutserverremotemanagement.
Chapter6.Replacinghardware117
