10.Removethenewmicroprocessorfromtheprotectivecoverthatprotectsthegoldcontactsonthe
bottomofthenewmicroprocessor.Donottouchthepinsonthemicroprocessorsocketandthegold
contactsonthebottomofthenewmicroprocessor.
Figure104.Donottouchthepins
11.Notetheorientationofthenewmicroprocessor.Holdthenewmicroprocessorbyitsedgesandalign
thenotches1onitwiththetabs2inthemicroprocessorsocket.Then,carefullylowerthenew
microprocessorstraightdownintothemicroprocessorsocket.
Note:Thesmalltriangle3ononecornerofthenewmicroprocessoristhemicroprocessororientation
indicator.Thenewmicroprocessorisinthecorrectorientationwhenthisindicatorfacesthebeveled
corner
4ofthemicroprocessorsocket.
Figure105.Installingthemicroprocessor
Chapter6.Replacinghardware133
