•Tocompletethereplacement,goto“Completingthepartsreplacement”onpage178.
InstallingorremovingtheThinkServerRAIDSuperCapacitorModule
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage63.
TheThinkServerRAIDSuperCapacitorModuleprotectsthecachememoryontheinstalledThinkServer
RAIDcard.YoucanpurchaseaThinkServerRAIDSuperCapacitorModulefromLenovo.
ForalistofThinkServeroptions,goto:
http://lenovoquickpick.com/usa/home/thinkserver/rack-and-tower-server
InstallingtheThinkServerRAIDSuperCapacitorModule
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage63.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•YoucaninstalltwoThinkServerRAIDSuperCapacitorModulesonthecoolingshroud.
•UseanydocumentationthatcomeswiththeThinkServerRAIDSuperCapacitorModuleandfollowthose
instructionsinadditiontotheinstructionsinthistopic.
ToinstalltheThinkServerRAIDSuperCapacitorModule,dothefollowing:
1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
2.Prepareyourserver.See“Removingorextendingtheserverfromtherackcabinet”onpage65.
3.Removetheservercover.See“Removingtheservercover”onpage65.
4.Touchthestatic-protectivepackagethatcontainstheThinkServerRAIDSuperCapacitorModuleto
anyunpaintedsurfaceontheoutsideoftheserver.Then,taketheThinkServerRAIDSuperCapacitor
Moduleoutofthepackage.
Chapter6.Replacinghardware135
