5.NotetheorientationoftheThinkServerRAIDSuperCapacitorModule.Then,gentlypressthetab
onthecoolingshroudasshownandinstalltheThinkServerRAIDSuperCapacitorModuleontothe
coolingshroudatthesametime.
Figure108.InstallingtheThinkServerRAIDSuperCapacitorModuleontothecoolingshroud
6.ConnecttheThinkServerRAIDSuperCapacitorModuletoaRAIDcard.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage178.
RemovingtheThinkServerRAIDSuperCapacitorModule
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage63.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:UseanydocumentationthatcomeswiththeThinkServerRAIDSuperCapacitorModuleandfollow
thoseinstructionsinadditiontotheinstructionsinthistopic.
ToremovetheThinkServerRAIDSuperCapacitorModule,dothefollowing:
1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
2.Prepareyourserver.See“Removingorextendingtheserverfromtherackcabinet”onpage65.
3.Removetheservercover.See“Removingtheservercover”onpage65.
4.DisconnectthecableoftheThinkServerRAIDSuperCapacitorModulefromtheRAIDcard.
