2.Pressthecircledarea1toopenthehandleofthedummytray.
Figure120.Openingthehandleofthedummytray
3.Pullthehandleandcarefullyslidethedummytrayoutofthefrontofthechassis.
Figure121.Removingthedummytray
4.Touchthestatic-protectivepackagethatcontainsthe2.5-inchdrivetoanyunpaintedsurfaceonthe
outsideoftheserver.Then,takethedriveoutofthepackage.
Note:Donottouchthecircuitboardonthedrive.
5.Positionthe2.5-inchdriveintothe3.5-inchto2.5-inchdriveadapterasshowninthefollowingillustration.
Figure122.Positioningthe2.5-inchdriveintothedriveadapter
144ThinkServerRD450UserGuideandHardwareMaintenanceManual
