Figure11.Removingthememoryfanduct
7.Opentheretainingclipsasshown.
Figure12.Openingtheretainingclips
Ifyouarereplacinganoldmemorymodule,opentheretainingclipsandgentlypullthememorymodule
outofthememoryslot.
Figure13.Removingamemorymodule
Notes:
a.Ifyourcomputerhas12memoryslotsonthesystemboard,youmighthavetousemoreforceto
removethememorymodulesinstalledinmemoryslots1and2.
Chapter2.Installingorreplacinghardware19
