Power distribution board for the fixed power supply
Figure 11. Power distribution board for the fixed power supply
Table 16. Power distribution board for the fixed power supply
1 Power supply system power connector
3 System power connector
2 Power supply processor power connector 4 Processor power connector
Power distribution board for hot-swap power supplies
Figure 12. Power distribution board for hot-swap power supplies
Table 17. Power distribution board for hot-swap power supplies
1 Processor power connector
3 System power connector
2 Side band connector
Chapter 2. Server components 31
