Commissioning
5-20
BA9300POS EN 2.3
5.8.2 Save parameter set
The operating menu GDC (see Fig. 5-16) allows you to save a new or modified parameter set:
• Saving on the hard drive of the PC or a diskette by
”Write all parameter sets to file”
• Saving in the controller by
”Write current parameter set to the controller (F5)”
– You can save the data as non-volatile with C0003=1 in the ”Parameter set management”
menu.
Tip!
Comments can be entered for the parameter set when saving on the hard drive or diskette.
1. Click on ”Drive parameters” in the menu bar of GDC.
Fig. 5-16 Dialog box ”Write parameter set to file”
2. Select ”Write all parameter sets to file”.
3. Enter the file names and select the disk drive on which you want to save the parameter set.
4. Write a comment on the parameter set in the ”Commentary” field and confirm with ”Ok”.
