Lenze 9300 - Basic configuration

Configuration
7-4

BA9300POS EN 2.3
7.2.3 Monitoring functions
Overview of the fault sources detected by the controller, and the corresponding reactions
Display Meaning TRIP Meldung War n in g FAIL-QSP off Code
CCr System error • - - - - -
CE0 Communication error (AIF) á - á - • C0126
CE1 Communication error at the process data input object
CAN-IN1 (time monitoring can be set under C0357/1)
á - á - • C0591
CE2 Communication error at the process data input object
CAN-IN2 (time monitoring can be set under C0357/2)
á - á - • C0592
CE3 Communication error at the process data input object
CAN-IN3 (time monitoring can be set under C0357/3)
á - á - • C0593
CE4 BUS-OFF state (many communication errors occurred) á - á - • C0595
EEr External monitoring • á á á á C0581
H05, H07 Internal error • - - - - -
H10 Sensor fault heatsink temperature • - - - á
C0588
H11 Sensor fault: internal temperature • - - - á
LP1 Motor phase failure detection (function block must be
entered in C0465)
á - á - • C0597
LU Undervoltage - • - - - -
NMAX Maximum speed exceeded (C0596) • - - - - -
OC1 Short circuit • - - - - -
OC2 Earth fault • - - - - -
OC5 Ixtoverload • - - - - -
OH Heatsink temperature 1 (max. permissible, fixed) • - - - - -
OH3 Motor temperature 1 (max. permissible, fixed) • - - - á C0583
OH4 Heatsink temperature 2 (adjustable; C0122) - - • - á C0582
OH7 Motor temperature 2 (can be set; code: C0121) - - • - á C0584
OH8 Motor temperature (fixed) via inputs T1/T2 á - á * - • C0585
OU Overvoltage in the DC bus - • - - - -
P01 Limit switch negative = LOW á - - • - C1285/1
P02 Limit switch positive = LOW á - - • - C1285/2
P03 Contouring error - digital frequency > C0255 á - • - á C0589
P04 Position limit exceeded in negative direction á - - • - C1285/3
P05 Position limit exceeded in positive direction á - - • - C1285/4
P06 No reference á - - • - C1287/1
P07 Parameter set mode absolute á - - • - C1291/1
P08 Actual offset out of range á - - • - C1291/2
P09 Impermissible programming á - - • - C1291/3
P12 Encoder range exceeded á - - • - C1288/1
P13 Phase overflow • - á - á C0590
P14 1st contouring error POS > C1218/1 á - á • á C1286/1
P15 2nd contouring error POS > C1218/2 á - á á • C1286/2
P16 Sync error á - á • á C1290/1
P17 TP control error á - á • á C1289/1
P18 Internal limitation á - • á á C1289/2
PEr Program error • - - - - -
PI Fault during initialization • - - - - -
PR0 General fault in parameter sets • - - - - -
PR1 Fault in parameter set 1 • - - - - -
Sd2 Resolve r fault • - á * - á C0586
Sd3 Encoder fault at X9 PIN 8 á - á * - • C0587
