Lenze AC Tech M3103S User Manual

6 M301L
HP
(kW)
INPUT
VOLTAGE MODEL H W D N P Q R S
5
(3.7)
240 / 200 M3250 7.88 7.86 5.94 5.13 3.95 1.50 5.88 1.13
480 / 400 M3450 7.50 6.12 5.12 3.77 3.30 1.37 5.50 0.88
590 M3551 7.88 7.86 5.94 5.13 3.95 1.50 5.88 1.13
7.5
(5.5)
240 / 200 M3275 9.38 7.86 6.84 3.93 4.19 2.00 5.88 1.13
480 / 400 M3475 9.38 7.86 6.25 5.13 3.95 1.50 7.38 1.13
590 M3575 9.38 7.86 6.25 5.13 3.95 1.50 7.38 1.13
10
(7.5)
240 / 200 M32100 11.25 7.86 6.84 3.93 4.19 2.00 7.75 1.38
480 / 400 M34100 9.38 7.86 6.84 3.93 4.19 2.00 5.88 1.13
590 M35100 9.38 7.86 7.40 3.93 4.19 2.00 5.88 1.13
15
(11)
240/200 M32150 12.75 7.86 6.84 3.93 4.19 2.00 9.25 1.38
480/400 M34150 11.25 7.86 6.84 3.93 4.19 2.00 7.75 1.38
590 M35150 12.75 7.86 6.84 3.93 4.19 2.00 9.25 1.38
20
(15)
240 / 200 M32200 12.75 10.26 7.74 5.13 5.00 2.50 9.25 1.38
480/400 M34200 12.75 7.86 6.84 3.93 4.19 2.00 9.25 1.38
590 M35200 12.75 7.86 7.40 3.93 4.19 2.00 9.25 1.38
25
(18.5)
240 / 200 M32250 15.75 10.26 8.35 5.13 5.00 2.50 12.25 1.38
480/400 M34250 12.75 10.26 7.74 5.13 5.00 2.50 9.25 1.38
590 M35250 12.75 10.26 7.74 5.13 5.00 2.50 9.25 1.38
30
(22)
240 / 200 M32300 15.75 10.26 8.35 5.13 5.00 2.50 12.25 1.38
480/400 M34300 12.75 10.26 7.74 5.13 5.00 2.50 9.25 1.38
590 M35300 12.75 10.26 8.25 5.13 5.00 2.50 9.25 1.38
40
(30)
480/400 M34400 15.75 10.26 8.35 5.13 5.00 2.50 12.25 1.38
590 M35400 15.75 10.26 8.35 5.13 5.00 2.50 12.25 1.38
50
(37.5)
480/400 M34500 19.75 10.26 8.55 5.13 5.75 2.50 16.25 1.75
590 M35500 19.75 10.26 8.55 5.13 5.75 2.50 16.25 1.75
60
(45)
480/400 M34600 19.75 10.26 8.55 5.13 5.75 2.50 16.25 1.75
590 M35600 19.75 10.26 8.55 5.13 5.75 2.50 16.25 1.75
DIMENSIONS - CHASSIS AND TYPE 1 ENCLOSED (continued)
