M301L 27
RUN > 460 VAC
DRIVE
STATUS
MOTOR
VOLTAGE
DIRECTION
(FORWARD)
NOTE
During acceleration and deceleration to the SPEED SETPOINT, the
DRIVE STATUS will show the actual drive speed. When the SPEED
SETPOINT is reached, the DRIVE STATUS will change to RUN (or
STOP if the drive is decelerating to a STOP).
13.2.3 MC3000 DISPLAY IN FAULT MODE
When the drive trips on a fault, the display will automatically change to the FAULT display,
which indicates the FAULT MESSAGE:
FAULT: OVERLOAD
DRIVE
STATUS
FAULT
MESSAGE
In FAULT mode, the ENTER key will toggle the display between four screens: FAULT,
SPEED, % LOAD and VAC. The DRIVE STATUS for these displays will be FAULT. An
example is shown below of the drive in the FAULT mode displaying SPEED.
FAULT > 60.00 HZ
DRIVE
STATUS
SPEED
SETPOINT
SPEED
UNITS
DIRECTION
(FORWARD)
NOTE
To clear a FAULT, press the STOP key, issue a remote STOP
command at TB-1, or use TB-13D (refer to Parameter 50 - TB13D).
