3 MC3000 MODEL DESIGNATION CODE
The model number of an MC3000 Series drive gives a full description of the basic drive
unit (see example below).
EXAMPLE: M3450BP
(MC3000, 480 Vac, 5 HP, Type 1 Enclosure, with a Remote Keypad Assembly)
M3 4 50 B P
Series:
M3 = M3000 Series Variable Speed AC Motor Drive
Input Voltage:
1 = 240/120 Vac (For 110, 115, 120, 230 and 240 Vac; 50 or 60 Hz)
2 = 240/200 Vac (For 208, 230, and 240 Vac; 50 or 60 Hz)
4 = 480/400 Vac (For 380, 415, 440, 460 and 480 Vac; 50 or 60 Hz)
5 = 590/480 Vac (For 440, 460, 480, 575 and 600 Vac; 50 or 60 Hz)
Rating:
03 = ¼ HP (0.18 kW) 50 / 51 = 5 HP (3.7 kW) 300 = 30 HP (22 kW)
05 = ½ HP (0.37 kW) 75 = 7½ HP (5.5 kW) 400 = 40 HP (30 kW)
10 = 1 HP (0.75 kW) 100 = 10 HP (7.5 kW) 500 = 50 HP (37.5 kW)
15 = 1½ HP (1.1 kW) 150 = 15 HP (11 kW) 600 = 60 HP (45 kW)
20 = 2 HP (1.5 kW) 200 = 20 HP (15 kW)
30 = 3 HP (2.2 kW) 250 = 25 HP (18.5 kW)
Input Phase:
S = Single phase input only.
No character indicates three phase input only
Enclosure Type:
A = Chassis - Open Enclosure with Cover Removed
B = NEMA 1 - General Purpose, vented
C = NEMA 4 - Water-tight and Dust-tight
D = NEMA 12 - Oil-tight and Dust-tight
E = NEMA 4X - Water-tight, Dust-tight, and Corrosion Resistant (Stainless Steel)
Standard Options:
H = Additional Form C Relay circuit board
J = Dynamic Braking circuit board
K = Dynamic Braking & Additional Form C Relay board (not available on all HP sizes - consult factory)
No character when this type of option is not specified
Interface Options:
P = Remote keypad assembly
No character when this type of option is not specified
