M301L 37
16 PROGRAMMING THE MC3000 DRIVE
16.1 PROGRAMMING THE PARAMETERS
The MC3000 keypad serves two purposes: operating the drive when in the LOCAL mode,
and programming the parameters for particular applications. The keypad is shown below,
along with the display that should appear when the drive is first powered up:
AUTO
LOCAL
STOP > 20.00 HZ
START
STOP
ENTER
REMOTE
MAN
PROG
RUN
To program the drive, the PROGRAM mode must be entered by pressing the PROG/
RUN button. If the password protection is disabled, pressing the PROG/RUN button will
result in direct entry into the PROGRAM mode. If the password protection is enabled,
the PASSWORD prompt will appear when an attempt is made to enter the PROGRAM
mode. The PASSWORD prompt appears as follows:
PASSWORD 0000
CURSOR
To enter the password, use the UP and DOWN arrow keys to scroll to the password
value, and then press the ENTER key.
NOTE
The factory default password is 0019.
