38 M301L
Once the correct password is entered, the PROGRAM mode will be entered and the first
parameter will be displayed, which is Parameter 0 - LINE VOLTS. This is shown below:
LINE VOLTS AUTO
PARAMETER
NAME
PARAMETER
VALUE
CURSOR
To scroll through the parameters, use the and keys on the keypad. When the desired
parameter is found, press the ENTER key to shift the cursor from the parameter name
to the parameter value. In this example, the cursor shifts from LINE VOLTS to AUTO:
LINE VOLTS AUTO
PARAMETER
NAME
PARAMETER
VALUE
CURSOR
The parameter value can then be changed using the and keys. If the parameter
has a numerical value, the key will increase the value and the key will decrease the
value. If the parameter has specific choices that can be selected, the and keys will
scroll through the list of possible settings. When the desired value or option is selected,
press the ENTER key to store the new setting. If the new setting is not ENTERED, it will
not take effect and the old setting will still be valid.
If the PROG/RUN key is pushed while the cursor is highlighting the parameter value, the
value will change back to the original setting (if it had been changed, but not ENTERED),
and the cursor will shift back to the parameter name. Pressing PROG/RUN again will
exit the PROGRAM mode. If the PROGRAM mode is entered again within two minutes,
the last parameter that was viewed, or changed, will come up on the display. After two
minutes has elapsed, the password will have to be entered again when attempting to
access the PROGRAM mode.
