M301L 9
5 MC3000 RATINGS
The following tables indicate the input and output ratings of the MC3000 Series drive.
NOTE: The output current ratings are based on operation at carrier frequencies of 8 kHz
and below. At full ambient temperature, operation at carrier frequencies above
8 kHz requires derating the drive by multiplying the output current rating by the
following factors: 0.94 at 10 kHz, 0.89 at 12 kHz, and 0.83 at 14 kHz. Refer to
Parameter 23 - CARRIER in Section 18 - DESCRIPTION OF PARAMETERS.
M3100 SERIES RATINGS
MODEL
INPUT OUTPUT
(200/240 Vac, 50 - 60 Hz) (0 - 200/230 Vac)
MODEL
NUMBER
1
FOR MOTORS
RATED
INPUT
PHASE
NOMINAL
CURRENT
2
(AMPS)
POWER
(KVA)
NOMINAL
CURRENT
(AMPS)
POWER
(KVA)
HP kW
M3103S 0.25 0.18 1 6.0 / 3.0 0.7 1.4 0.56
M3105S 0.5 0.37 1 9.2 / 4.6 1.1 2.2 0.88
M3110S 1 0.75 1 16.2 / 8.1 1.9 4.0 1.6
M3115S 1.5 1.1 1 21 / 10.4 2.5 5.2 2.1
1
Refer to Section 3 for model number breakdown.
2
Refer to Section 8 for recommended fuse type.
M3200 SERIES RATINGS
MODEL
INPUT OUTPUT
(200/240 Vac, 50 - 60 Hz) (0 - 200/230 Vac)
MODEL
NUMBER
1
FOR MOTORS
RATED
INPUT
PHASE
NOMINAL
CURRENT
2
(AMPS)
POWER
(KVA)
NOMINAL
CURRENT
(AMPS)
POWER
(KVA)
HP kW
M3205S 0.5 0.37 1 5.8 / 5.0 1.2 2.5 / 2.2 0.9
M3205 0.5 0.37 3 3.1 / 2.7 1.1 2.5 / 2.2 0.9
M3210S 1 0.75 1 10.3 / 9.0 2.2 4.6 / 4.0 1.6
M3210 1 0.75 3 5.5 / 4.8 2.0 4.6 / 4.0 1.6
M3215S 1.5 1.1 1 13.3 / 11.6 2.8 6.0 / 5.2 2.1
M3215 1.5 1.1 3 7.1 / 6.2 2.6 6.0 / 5.2 2.1
M3220S 2 1.5 1 17.1 / 14.9 3.6 7.8 / 6.8 2.7
M3220 2 1.5 3 9.3 / 8.1 3.4 7.8 / 6.8 2.7
M3230S 3 2.2 1 24 / 21 5.0 11.0 / 9.6 3.8
M3230 3 2.2 3 13.0 / 11.3 4.7 11.0 / 9.6 3.8
M3250 5 3.7 3 20 / 17.7 7.4 17.5 / 15.2 6.1
M3275 7.5 5.5 3 30 / 26 10.6 25 / 22 8.8
M32100 10 7.5 3 37 / 32 13.2 32 / 28 11.2
M32150 15 11 3 55 / 48 19.8 48 / 42 16.7
M32200 20 15 3 70 / 61 25.3 62 / 54 21.5
M32250 25 18.5 3 89 / 77 32.0 78 / 68 27.1
M32300 30 22 3 104 / 90 37.6 92 / 80 31.9
1
Refer to Section 3 for model number breakdown.
2
Refer to Section 8 for recommended fuse type.
