M301L 43
PARAMETER MENU
PARAM.
NUMBER
PARAMETER
NAME
RANGE OF
ADJUSTMENT
FACTORY
DEFAULT
66 HISTORY
MAINTAIN
CLEAR
MAINTAIN
70 PID MODE
OFF
NORMAL
REVERSE
OFF
74 PID FB
TB-5A
TB-5B
TB-5A
75 FB @ MIN -32500 to 32500 0.0%
76 FB @ MAX -32500 to 32500 100.0%
77 P GAIN 0.0 - 999.9% 5.00%
78 I GAIN 0.0 - 10.0 SEC 0.0 SEC
79 D GAIN 0.0 - 10.0 SEC 0.0 SEC
80 PID ACC 0.0 - 100.0 SEC 30.0 SEC
81 MIN ALRM FB @ MIN - FB @ MAX 0.0%
82 MAX ALRM FB @ MIN - FB @ MAX 0.0%
98 LANGUAGE (NOTE 1) ENGLISH
99 FAULT HISTORY (VIEW - ONLY) (N/A)
NOTE 1: Refer to SECTION 18 - DESCRIPTION OF PARAMETERS
