Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0410

Free configuration
of digital input
signals
Link between digital signal sources and internal digital
signals
A selection made under C0007 is copied
to the corresponding subcode of C0410.
A change of C0410 sets C0007 = 255!
 7−68
1 NSET1−JOG1/3
NSET1−JOG1/3/5/7
(A)
1 Digital input X3/E1
Selection of fixed setpoints
C0410/1 C0410/2
C0410/33
LOW LOW LOW
HIGH LOW LOW
LOW HIGH LOW
... ... ...
HIGH HIGH HIGH
active
C0046
JOG1
JOG2
...
JOG7
2 NSET1−JOG2/3
NSET1−JOG2/3/6/7
(A)
2 Digital input X3/E2
3 DCTRL1−CW/CCW 4 Digital input X3/E4 CW = CW rotation
CCW = CCW rotation
LOW
HIGH
4 DCTRL1−QSP 255 Not assigned (FIXED−FREE) Quick stop (via terminal LOW active)
5 NSET1−RFG1−STOP 255 Not assigned (FIXED−FREE) Ramp function generator main setpoint stop
6 NSET1−RFG1−0 255 Not assigned (FIXED−FREE) Ramp function generator input must be set
to "0" for mains setpoint
7 MPOT1−UP 255 Not assigned (FIXED−FREE)
Motor potentiometer functions
8 MPOT1−DOWN 255 Not assigned (FIXED−FREE)
9 Reserved 255 Not assigned (FIXED−FREE) Do not change 255!
10 DCTRL1−CINH 255 Not assigned (FIXED−FREE) Controller inhibit (via terminal LOW active)
11 DCTRL1−TRIP−SET 255 Not assigned (FIXED−FREE) External error (via terminal LOW active)
12 DCTRL1−TRIP−RESE
T
255 Not assigned (FIXED−FREE) Error reset
13 DCTRL1−PAR2/4 255 Not assigned (FIXED−FREE) Parameter set changeover
(only possible if C0988 = 0)
C0410/13 and C0410/14 must have the
same source in every parameter sets
used. Otherwise it is not possible to
change between the parameter sets
(error message CE5 or CE7).
14 DCTRL1−PAR3/4 255 Not assigned (FIXED−FREE) C0410/13 C0410/14
LOW LOW
HIGH LOW
LOW HIGH
HIGH HIGH
active
PAR1
PAR2
PAR3
PAR4
15
MCTRL1−DCB 3 Digital input X3/E3 DC−injection brake
16
(A)
PCTRL1−RFG2−
LOADI
255 Not assigned (FIXED−FREE) Actual process controller value
(PCTRL1−ACT) must be connected to
process controller ramp function generator
(PCTRL1−RFG2)
17 DCTRL1−H/Re 255 Not assigned (FIXED−FREE) Manual/remote changeover
18 PCTRL1−I−OFF 255 Not assigned (FIXED−FREE) Switch off I−component of the process
controller
19 PCTRL1−OFF 255 Not assigned (FIXED−FREE) Process controller switch off
20 Reserved 255 Not assigned (FIXED−FREE) Do not change 255!
21 PCTRL1−STOP 255 Not assigned (FIXED−FREE) Process controller stop (value "frozen")
22 DCTRL1−CW/QSP 255 Not assigned (FIXED−FREE)
Failsafe change of the direction of rotation
23 DCTRL1−CCW/QSP 255 Not assigned (FIXED−FREE)
24 DFIN1−ON 255 Not assigned (FIXED−FREE) 0 = Frequency input not active
1 = Frequency input active
Frequency input configuration under C0425
and C0426
