Lenze E82MV152_4B

Function library
Free connection of digital signals, message output
7−70
L
EDB82MV752 EN 5.2
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0410

(cont.)
 7−68
25
(A)
PCTRL1−FOLL1−0 255 Not assigned (FIXED−FREE) Compensator at reset ramp C0193 to "0"
26
(A)
Reserved 255 Not assigned (FIXED−FREE)
27
(A)
NSET1−TI1/3 255 Not assigned (FIXED−FREE) Activate acceleration times
28
(A)
NSET1−TI2/3 255 Not assigned (FIXED−FREE) C0410/27 C0410/28
LOW LOW
HIGH LOW
LOW HIGH
HIGH HIGH
active
C0012; C0013
T
ir
1; T
if
1
T
ir
2; T
if
2
T
ir
3; T
if
3
29
(A)
PCTRL1−FADING 255 Not assigned (FIXED−FREE) Process controller output on (LOW)/ off
(HIGH)
30
(A)
PCTRL1−INV−ON 255 Not assigned (FIXED−FREE) Process controller output inversion
31
(A)
PCTRL1−NADD−OFF 255 Not assigned (FIXED−FREE) Switch off additional setpoint
32
(A)
PCTRL1−RFG2−0 255 Not assigned (FIXED−FREE) Decelerate process controller ramp function
generator input to "0" along ramp C0226
33
(A)
NSET1−JOG4/5/6/7 255 Not assigned (FIXED−FREE)
