Function library
Free connection of digital signals, message output
7−75
L
EDB82MV752 EN 5.2
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0415

(cont.)
Possible digital signals for C0415
 7−73
20 Apparent motor current < current threshold
(DCTRL1−IMOT<ILIM)
V−belt monitoring
Apparent motor current = C0054
Current threshold = C0156
Frequency threshold Q
min
= C0017
21 Apparent motor current < current threshold and
output frequency > Frequency threshold Q
min
(DCTRL1−(IMOT<ILIM)−QMIN)
22 Apparent motor current < current threshold and
ramp function generator 1: input = output
(DCTRL1−(IMOT<ILIM)−RFG−I=0)
23 Motor phase failure warning (DCTRL1−LP1−WARN) Set C0597 = 2
24 Minimum output frequency reached (f  C0010)
(PCTRL1−NMIN)
LOW active
25 TRIP error message (DCTRL1−TRIP)
26 Motor is running (DCTRL1−RUN)
27 Motor is running / CW rotation (DCTRL1−RUN−CW)
28 Motor is running / CCW rotation
(DCTRL1−RUN−CCW)
29 Process controller input = process controller
output (PCTRL1−SET=ACT)
30 Reserved
31 Apparent motor current > Current threshold and
ramp function generator 1: input = output
(DCTRL1−(IMOT>ILIM)−RFG−I=0)
Overload monitoring
Apparent motor current = C0054
Current threshold = C0156
32 Digital input X3/E1
digital inputs
33 Digital input X3/E2
34 Digital input X3/E3
35 Digital input X3/E4
36 (A) Digital input X3/E5
37 (A) Digital input X3/E6
38 PTC input X2.2/T1, X2.2/T2 Only connect potential−free switches to
T1/T2!
T1/T2 is active ("HIGH") when the switch is
closed
