Lenze E82MV152_4B

Function library
Free connection of digital signals, message output
7−76
L
EDB82MV752 EN 5.2
Code IMPORTANTPossible settings
No. SelectionLenzeName
C0415

(cont.)
Possible digital signals for C0415
 7−68
AIF control word (AIF−CTRL)
Permanently assigned bits of AIF−CTRL:
Bit 3: QSP
Bit 7: CINH
Bit 10: TRIP−SET
Bit 11: TRIP−RESET
40 Bit 0
...
...
55
Bit 15
CAN−IN1.W1 or FIF−IN.W1
60 Bit 0
...
...
75
Bit 15
CAN−IN1.W2 or FIF−IN.W2
80 Bit 0
...
...
95
Bit 15
CAN−IN2.W1
100 Bit 0
...
...
115
Bit 15
CAN−IN2.W2
120 Bit 0
...
...
135
Bit 15
Status application I/O
Only active for operation with application
I/O
140 Torque threshold 1 reached (MSET1=MOUT)
141
Torque threshold 2 reached (MSET2=MOUT)
142
Limitation of process controller output reached
(PCTRL1−LIM)
143 ...
172
Reserved
255
Not assigned (FIXED−FREE)
C0416

Level inversion −
digital outputs
0
0 Level inversion switched off By entering the sum of the selected values
you can invert several outputs.
 7−73
1 Relay K1
1
or digital switching output K1
2
1: applies to version 151
2: applies to version 152
2 X3/A1
4 X3/A2 Only application I/O
8 Relay K2 Relay output K2 only with
8200 vector 15 ... 90 kW
C0423*
(A)
Delay of digital
outputs
0.000 {0.001 s} 65.000 "Debouncing" of the digital outputs
(from version: application I/O E82ZAFA ...
Vx11)
 Switches the digital output if the linked
signal is still active after the time set.
 The digital output is reset without delay
 7−73
1 Device version 151:
relay output K1
(RELAY)
Device version 152,
153:
Digital switching
output K1
0.000
2 Digital output X3/A1
(DIGOUT1)
0.000
3 Digital output X3/A2
(DIGOUT2)
0.000
Signal linkage
The digital outputs are linked with the internal digital signals by entering the selection figure of the
internal signal in the corresponding subcode of C0415. C0415 can be different for the parameter
sets.
