Application examples
Pressure control
13−3
L EDB82MV752 EN 5.2
Jumper position at application I/O
Jumper A in 7−9 position (actual pressure 0 ... 10 V at X3/1U)
Remove jumper B (setpoint selection via master current at X3/2I), (observe C0034)
Plug jumper C into 3−5 position (actual pressure value is output as current signal to X3/62)
Jumper D in 2−4 or 4−6 position since X3/63 is not assigned.
Tip!
For this example the controller must be equipped with an application I/O since two analog
inputs are required.
If the pressure setpoint is not selected via PLC but via PC, keypad, or fixed setpoint, a
standard I/O is sufficient.
