Lenze E82MV152_4B

Parameter setting
With communication module LECOM−A (RS232)
6−13
L
EDB82MV752 EN 5.2
Code Parameter Important
No. Designation LECOM
format
Settings/options
C0068
*
Operating status VH
Bit Assignment
3|2|1|0 TRIP error number Submission of the 10th digit of the LECOM error number.
Example: TRIP OH (LECOM no. 50) = 0110 (5)
7|6|5|4 Last communication error
0000 No error
0001
Checksum error
0010
Protocol frame error
0011
Reserved
0100
Invalid code number
0101
Invalid variable value
0110
No access authorisation
0111
Telegram processing interrupted by
new telegram
1111
General error
8
0
1
Controller inhibit (DCTRL1−CINH)
Controller inhibited
Controller enabled
9
0
1
Q
min
threshold reached (PCTRL1−QMIN)
Not reached
Reached
10
0
1
Direction of rotation (NSET1/CW/CCW)
CW rotation
CCW rotation
11
0
1
Pulse inhibit (DCTRL1−IMP)
Power outputs inhibited
Power outputs enabled
12
0
1
Quick stop (DCTRL1−QSP)
Not active
Active
13
0
1
I
max
limit reached (MCTRL1−IMAX)
(C0014 = −5−: torque setpoint)
Not reached
Reached
14
0
1
Frequency setpoint reached
(MCTRL1−RFG1=NOUT)
Wrong
True
15
0
1
TRIP error message (DCTRL1−TRIP)
Not active
Active
C0248
*
LECOM input
selection
VD 0 0000 ... 0255  For compatibility with LECOM−A/B drivers V1.0 which do not
support the direct addressing of subcodes (array parameters).
 C0248 determines the subcode (array element) which is accessed.
 The attempt to access codes without subcodes with C0248 > 0,
causes an error since the address does not exist.
 LECOM-A/B drivers from V2.0 on support the direct addressing of
subcodes. Do not use C0248 together with these drivers!
 With every switch−on, C0248 is set to 0.
