Parameter setting
With communication module LECOM−A (RS232)
6−14
L
EDB82MV752 EN 5.2
Code ImportantParameter
No. Settings/optionsLECOM
format
Designation
C0249
*
LECOM code
bank
VD
Code bank Addressable codes
For compatibility with LECOM−A/B drivers V1.0 (maximum possible
code number 255).
With the code bank, an offset of 250 is added to the code number.
Together with LECOM.A/B drivers from V2.0 on, C0249 is
ineffective.
With every switch−on, C0249 is set to 0.
0 0000 ... 0255
1
0250 ... 0505
2
0500 ... 0755
3
0750 ... 1005
4
1000 ... 1255
5
1250 ... 1505
6
1500 ... 1755
7
1750 ... 2005
8
2000 ... 2255
9
2250 ... 2505
10
2500 ... 2755
11
2750 ... 3005
12
3000 ... 3255
13
3250 ... 3505
14
3500 ... 3755
15
3750 ... 4005
C1810
*
SW
identification
VS Structure: 33S2102I_xy000 Software identification (x = main version, y = subversion)
C1811
*
SW creation VS Date of software creation
C1920 Starting status VD
0 QSP (quick stop) After mains switching the drive is in QSP" status.
1 CINH (controller inhibit) After mains switching the drive is in CINH" status.
Writing of C0040 =1 enable
C1921 Reduced
response time
VD
0 Not active
C1921 = 1:
A write telegram (send) is only checked for transmission errors:
– A faulty telegram is acknowledged positively (ACK), otherwise
negatively (NAK).
– Only after this the value is transmitted to the controller.
It is not guaranteed that the controller has adopted the value
correctly.
The communication module can be readdressed after 50 ms.
1 Active
C1922
Communication
monitoring
response
VD
0 Not active
Use C1922 and C1923 to monitor the communication connection to
the host.
If the host does not send a telegram to the communication module
during the monitoring time set under C1923, the action set under
C1922 will be executed.
1 CINH (controller inhibit)
2
QSP (quick stop)
C1923
Monitoring time 50 {ms} 65535
