Overview of the implemented objects for the function module
9
l
63
EDS82ZAFVCxxx EN 4.0
Manufacturer−specific class 100 (64
hex
):
Access to Lenze codes
) Note!
We recommend the use of class 110 (¶ 65).
Instance 0:
Attribute Service(s) Description Data type Value
1 GET Revision UINT 0001
hex
Instance 1:
Attribute Service(s) Description Data type Value
1 GET/SET Explicit Message
Lenze Codes
See table below Dependent on order
Data type instance 1
Byte Request Response
1 Code Low Code Low
2 Code High Code High
3 Subcode Subcode
4 Reserve Status l Value of byte = 0: The message does not contain any faults.
l Value of the byte ¹0: Message is faulty.
The value of the byte indicates the fault number (for
explanation see the following table).
5
..
..
Data_1 Low
Data_1 Low
Data_1 High
Data_1 High
..
..
..
..
Data_22 Low
Data_22 Low
Data_22 High
Data_22 High
Explanation of the fault number:
Error code Explanation
03
hex
Invalid data type
04
hex
Subcode no. not accepted
05
hex
Code no. not accepted
07
hex
No right to access due to operating state
08
hex
No right to access due to operating mode
09
hex
No right to access as parameters are only readable
0A
hex
No general right to access
0B
hex
Data block too long
0C
hex
Collisions with other value ranges
0D
hex
Quit value range
0E
hex
Fault − general value range
2X
hex
Fault − AIF interface
FF
hex
General fault
Services:
Service code Name Description
0E
hex
Get_Attribute_Single Reading an attribute
10
hex
Set_Attribute_Single Writing of an attribute
