8400 StateLine C | Operating instructions
Adapting the application individually
Implementing more additional functions in the signal flow
68 L from Firmware V06.00 - DMS 1.1 EN - 11/2011
Parameter
Parameter Name Info/Lenze setting
Motor potentiometer
C00806 Use of motor potentiometer 0 The motor potentiometer is not used.
• The analog value applied to the nIn_a
input is looped through without any
changes to the nOut_a output.
1 The motor potentiometer is used.
• The analog value applied at the nIn_a
input is led via the motor
potentiometer and provided at the
nOut_a output.
C00800 L_MPot_1: Upper limit 100.00 %
C00801 L_MPot_1: Lower limit -100.00 %
C00802 L_MPot_1: Acceleration time 10.0 s
C00803 L_MPot_1: Deceleration time 10.0 s
C00804 L_MPot_1: Inactive fct. Behaviour of the motor potentiometer function when
being deactivated via the bInAct input:
0Keep output value
1 Deceleration via ramp to 0
2 Deceleration via ramp to the lower limit
(C00801)
3 Step change to 0
4 Jump to lower limit (C00800)
5 Acceleration via ramp to upper limit
(C00800)
C00805 L_MPot_1: Init fct. Behaviour of the motor potentiometer function when
the device is switched on:
0 Load last value
1Load lower limit
2Load 0
