3.2 Device features
ƒ Compact motor inverter
ƒ Modular design
ƒ Part of the Inverter Drives 8400 product family
– Identical product features
– Identical operation
ƒ Scalable fieldbus communication (optional)
ƒ On site diagnostics per status LEDs
ƒ Extensive accessories (optional)
ƒ Pluggable memory module
ƒ Quick commissioning via DIP switches
Features Version
Power range 0.75 ... 7.5 kW
Fieldbus communication
(optional)
–CANopen
–PROFIBUS
–AS-i
–EtherCAT
–PROFINET
– EtherNet/IP
Integrated interference
suppression according to
EN 61800-3
Flying restar t circuit
Integrated brake management
Integrated brake chopper
Integrated brake resistor Optional
Drive-based safety Optional: ”Safe torque off (STO)”
Operating modes – VFCplus: V/f open loop, linear and square-law
– SLVC: sensorless vector control (torque/speed)
– VFC eco (energy-saving function)
S-shaped ramps for smooth
acceleration and deceleration
Fixed frequencies 3
Overload current 200%(3s)
Usability on IT system
Incremental encoder
evaluation
Two-track, 10 kHz
Outputs Optional:
1 digital output
1 potential-free relay contact, 2 A, NO contact
DC-injection braking
Mounting Motor mounting
Optional: vertical wall mounting, cooling ribs on the top
General features
Functional features
