Commissioning
Quick commissioning
Commissioning steps
6
85
EDS84DG752 EN 5.0
6.2.2 Commissioning steps
Commissioning
Proceed step by step:
ƒ Switch on the mains
ƒ Observe status display
– After a short initialisation time, the display must be blinking green.
ƒ Deactivate requirements of the safety function
ƒ Set controller enable
– After the set starting time, the motor must rotate with the set speed.
ƒ First check of the expected behaviour:
– Direction of rotation?
– Starting time?
– Speed?
– Speed control?
ƒ Check of optional control functions:
– Does the analog setpoint selection work?
– Do the digital control signals, e.g. limit switches, work?
– Does the connected motor holding brake work?
– Does the change of direction of rotation work?
– Does the requirement of the safety function work?
– Do the control signals over fieldbus work?
ƒ Switch off drive
– Reduce speed
– Inhibit controller enable
–Switchoffmains
Note!
Save parameter settings safe against mains failure
In order to prevent parameter settings carried out in the device from being lost
by mains switching, you have to explicitly save the parameter set with mains
failure protection in the device.
