Commissioning
Overview of the commissioning steps with keypad
Short overview of the parameters for quick commissioning
6

93
EDS84DG752 EN 5.0
6.4.2 Short overview of the parameters for quick commissioning
The keypad menu ”Quick commissioning” provides access to all essential parameters to
commission the drive/application ”Speed actuating – drive” quickly and easily. When
these parameters are set to suitable and s ensible values, an error-free operation of the
controller is possible.
ƒ The ”Terminals” submenu contains the parameters for a control via terminals.
ƒ The ”Keypad” submenu contains the parameters for a control via keypad.
Parameter
Keypad display
Info Lenze setting Available in the submenu
Value Unit ”Terminals” ”Keypad”
C00002/1 Load Lenze setting Load Lenze setting 0: Off / ready  
C00007 Select control mode Select control mode 10: Terminals 0  
C00728/3 nMainSetValue_a Main setpoint 0.00 % - 
C00011 Appl.: Reference speed Reference speed 1500 rpm  
C00012 Accel. time - main
setpoint
Acceleration time - main
setpoint
2,000 s  
C00013 Decel. time - main
setpoint
Deceleration time -
main setpoint
2,000 s  
C00015 VFC: V/f base frequency V/f base frequency 50.0 Hz  
C00016 VFC: Vmin boost Vmin boost 2.60 %  
C00022 Imax (motor mode) Current limit (in motor
mode)
5.8 A  
C00087 Rated motor speed Rated motor speed 1320 rpm  
C00089 Rated motor freq. Rated motor frequency 50 Hz  
C00039/1 Fixed setpoint 1 Fixed setpoint 1 40.00 %  
C00039/2 Fixed setpoint 2 Fixed setpoint 2 60.00 %  -
C00039/3 Fixed setpoint 3 Fixed setpoint 3 80.00 %  -
C00727/3 bSetSpeedCcw Change of direction of
rotation
0 - 
C00727/4 bJogSpeed1 Selection of fixed
setpoint 1
0 - 
C00051 MCTRL: Act. speed val. Actual speed value - rpm  
C00054 Motor curr. Current motor current - A  
Display codes are shown in italics.
