3.4 Type code
3.4.1 Introducing information
Due to the modular structure of the 8400 motec controller, every unit needs an own type
key. Though, a type key is also defined for the 8400 motec controller as a set, it cannot be
attached visibly to the set or single units due to practical and logistical reasons.
The following lists inform you about the type keys for:
ƒ Wiring Unit
Wiring level to the motor and mains connection
ƒ Communication Unit
Connection level for fieldbus communication and further inputs and outputs, partially
optional
ƒ Drive unit
8400 motec controller
ƒ Accessories
Efficiency-improving and cost-reducing
3.4.2 The type codes
Wiring Unit
E84DGV N x E
Module part
Wiring Unit - 8400 motec
Version
N = not relevant
Size
1 = 063 / 071 (E84DGDVB3714 ... 1124)
2 = 080 / 090 / 100 (E84DGDVB5514 ... 1524)
3 = 080 / 090 / 100 / 112 (E84DGDVB2224 ... 3024)
4 = 080 / 090 / 100 / 112 (E84DGDVB4024 ... 7524)
5 = 132 (E84DGDVB5524 ... 7524)
Enclosure
E=IP66
