Commissioning
Handling of the keypad
6
86
EDS84DG752 EN 5.0
6.3 Handling of the keypad
The keypad X401 serves to quickly and easily set parameters and display current actual
values and device states by means of the corresponding display parameters. For this
purpose, the keypad must be plugged onto the diagnostic interface on the top of the
device.
Danger!
Uncontrolled motor movement possible
In general, changing a parameter causes an immediate response in the
controller.
Possible consequences:
ƒ This may lead to undesirable behaviour on the motor shaft if the controller
has been enabled.
Protective measures:
ƒ Make changes in small steps and wait for response.
ƒ Certain device commands or settings which may cause critical states of drive
behaviour constitute exceptions. Such parameter changes are only possible
if the controller is inhibited. Otherwise, a corresponding error message will
be issued.
Note!
The keypad can also be inserted/removed during operation.
Further information ....
Further information on the keypad can be found in the operating instructions
supplied with the keypad!
Menu structure
The main menu of the keypad contains the following entries:
Menu item Function
User menu Display of a selection of frequently required parameters.
Code list Display of the parameter list with all parameters.
Go to parameter Directly calls a certain parameter.
Local operation Control of the controller via the keypad keys.
Status Status display (current speed, motor current, device status).
