Commissioning
Handling of the keypad
6

87
EDS84DG752 EN 5.0
User menu
The user menu can be freely configured in C00517 and contains the following parameters
in the Lenze setting:
Parameter Name Info Lenze setting
Value Unit
C00002/19 Device command:
Reset error
After resetting the current error, further errors may be
pending which must be reset as well.
Details of the current error are displayed in C00166.
0 -
C00007 Control mode Selection of how the application is to be controlled. 10 -
C00011 Appl.: Reference
speed
Setting the reference speed 1500 rpm
C00012 Accel. time - main
setpoint
FB L_NSet_1: Acceleration time of the ramp generator
for t he main speed setpoint
2.0 s
C00013 Decel. time - main
setpoint
FB L_NSet_1: Deceleration time of the ramp generator
for t he main speed setpoint
2.0 s
C00015 VFC: V/f base
frequency
V/f base frequency for VFCplus motor control 50 Hz
C00016 VFC: Vmin boost Boost of the V/f voltage characteristic within the
range of low speed or frequency values for the
VFCplus motor control.
2.6 %
C00022 Imax in motor mode Maximum current in motor mode for all motor control
modes
5.8 A
C00039/1 Fixed setpoint 1
(L_NSet_1 n-Fix)
FB L_NSet_1: Fixed speed setpoints (JOG values) for
the setpoint g enerator
Fixed setpoint 1
40.0 %
C00039/2 Fixed setpoint 2 Fixed setpoint 2 60.0 %
C00039/3 Fixed setpoint 3 Fixed setpoint 3 80.0 %
C00087 Rated motor speed This value can be obtained from the motor nameplate.
After t he motor to be used has been selected from the
motor catalogue,
the suitable value can be entered automatically.
1320 rpm
C00089 Rated motor
frequency
This value can be obtain ed from the motor nameplate.
After t he motor to be used has been selected from the
motor catalogue,
the suitable value can be entered automatically.
50 Hz
C00105 Deceleration time -
quick stop
The set deceleration time determines the ramp slope
at quick stop
5.0 s
C00120 Motor overload
threshold (I
2
xt)
Operating threshold for the error message ”OC6:
Motor overload (I
2
xt)”
100 %
C00129 Value brake resistor Resistance value of the connected brake resistor 220 
C00165 Error information Display of the error numbers divided into sectors in
thecaseofanerror
- -
C00173 Mains voltage Selection of the mains voltage for operating the
device.
0: 400 V -
C02580 Holding brake:
Operating mode
Selection of the operating mode for holding brake
control
0: Off -
