Commissioning
Quick commissioning
General configuration settings
6
84
EDS84DG752 EN 5.0
Preconditions for initial switch-on
ƒ The wiring unit is mounted and wired according to the instructions,
– directly on a motor clamping flange or
– with the wall adapter on a suitable surface near the motor.
ƒ Connections with the mains, motor, holding brakes, etc. have been established.
ƒ The communication unit has been mounted and wired according to the scheduled
application.
– Input and output signals
– Safe input
– Fieldbus
(depending on the version, only available optionally)
ƒ If required, the basic settings for ”local mode” have been carried out.
–DIPswitches
– Potentiometer
ƒ The drive unit has been mounted and screwed together.
ƒ Use available control functions reasonably, e.g.
– Inhibit controller enable
– Set speed adjustment to the minimum setting
– Activate safety system
ƒ The use of a brake resistor has been checked.
– In the case of dynamic loads or difficult control conditions, the use of the internal
brake resistor E84DZEW47R0 is always recommended for the devices
E84DGDVB4024 ... 7524 (4 ... 7.5 kW).
Danger!
High hazard potential during commissioning
Incorrect settings may cause unexpected and dangerous motor and system
movements.
Possible consequences:
ƒ Damage to material assets
ƒ Injury to persons
Protective measures:
ƒ Clear hazardous area
ƒ Observe safety instructions and safety clearances
