Lenze E84DGDVB7514 User Manual

Product description
Type code
Thetypecodes
3

24
EDS84DG752 EN 5.0
8400 motec Set

E84DV B x xxx x S x x x 2 x x
Product range
Inverter Drives 8400 motec
Version
B = not relevant
Design
M = motor-mounted device
W = wall-mounted device
Power e.g.
152=15x10
2
W=1.5kW
Voltage class
4 = 400/480 V, 3/PE AC (also for IT systems)
Control element
S = standard (DIP switch es/ potentiometer/X70)
Communication (fieldbus)
N = NO BUS (without fieldbus)
A=AS-i
C=CANopen
G = EtherNet/IP
P = PROFIBUS
R=PROFINET
S = standard I/O
T=EtherCAT
Connection system - communication and IO
N=NOBUS/standardIO:Terminal
A = communication: M12, IO: Terminal
9 = communication: M12, IO: M12
Drive-based safety
N = none
J = safety option 10 (safe torque off)
(incl. supplements IO)
Memory module
2=formotec
Enclosure
P=IP65
E= IP66
Size
1 = 063 / 071 (E84DGDVB3714 ... 1124)
2 = 080 / 090 / 100 (E84DGDVB5514 ... 1524)
3 = 080 / 090 / 100 / 112 (E84DGDVB2224 ... 3024)
4 = 080 / 090 / 100 / 112 (E84DGDVB4024 ... 7524)
5 = 132 (E84DGDVB5524 ... 7524)
