Technical data
General data and operating conditions
4

27
EDS84DG752 EN 5.0
Protection of persons and equipment
Enclosure
EN 60529
IP65
optional: IP66
in ready-for-use state:
 Close unused bores for cable
glands with blanking plugs!
 Close unused connectors with
protection covers or blanking
plugs!
NEMA 250 Protection a ccording to
 Type 4
(Earth) leakage current EN 61800-5-1 > 3.5 mA AC, > 10 mA DC Observe the regulations and
safety instructions!
Total fault current In TN systems the following earth-leakage circuit breakers
can be used:
Motor mounting
E84DGDVB3714
...
E84DGDVB1524
30 mA, type B
E84DGDVB2224
...
E84DGDVB7524
300 mA, type B
Wall mounting E84DGDVB3714
...
E84DGDVB7524
300 mA, type B
Additional equipotential
bonding
M5 thread with terminal in the WU for connection of a
16mm@ PE cable
Protective insulation of
control circuits
EN 61800-5-1 Safe isolation from mains by double (reinforced) insulation
Insulation resistance EN 61800-5-1
Site altitude
0 ... 2000 m Overvoltage category III
2000 ... 4000 m Overvoltage category II
Short-circuit strength EN 61800-5-1
Connection:
Motor To a limited extent, the
controller is inhibited, error
acknowledgement required
Motor holding brake, brake
resistor
No
PTC, control terminals Full
Earth-fault strength EN 61800-5-1
Connection:
Motor (at controller
enable)
To a limited extent, the
controller is inhibited, error
acknowledgement required
Motor (during operation) No
Brake resistor, PTC No
Protective measures
against
 Short circuit on the motor side at switch-on and during
operation
 Motor stalling
 Motor overtemperature
– Input for PTC or thermal contact
–I
2
t monitoring
Cyclic mains switching
 Switchings/minute 3
 Switchings/hour Max. 20
 Switching pause After switching the mains 3
times in one minute, there must
be a switching pause of
9 minutes.
Starting current  2xI
N
