Technical data
General data and operating conditions
4
29
EDS84DG752 EN 5.0
EMC
Noise emission (in TN and TT mains)
Cable-guided
EN 61800-3
Motor mounting
E84DVBM3714 ... 1524 Category C1
E84DVBM2224 ... 3024
for switching frequency
4kHz
Category C1
E84DVBM4024 ... 7524 Category C2
Wall mounting EN 61800-3
E84DVBW3714 ... 7524
for switching frequency
4kHzand
with Lenze system cable
20 m
Category C2
E84DVBW3714 ... 7524 for
switching frequency
8kHzand
with Lenze system cable
10 m
Category C2
Radiation EN 61800-3
E84DVBM3714 ... 1524
for switching frequency
8kHz
Category C1
E84DVBM2224 ... 7524
for switching frequency
8kHz
Category C2
Noise i mmunity (according to requirements of EN 61800-3)
Electrostatic discharge
(ESD)
EN 61000-4-2 8 kV with air discharge,
4 kV w ith c ontact discharge against housing
Radio frequency
Conducted EN 61000-4-6 150 kHz ... 80 MHz, 10 V/m 80 % AM (1kHz)
Interference
(housing)
EN 61000-4-3 80 MHz ... 1000 MHz, 10 V/m 80 % AM (1kHz)
Burst
Power terminals and
interfaces
EN 61000-4-4 2kV/5kHz
Signal interfaces EN 61000-4-4 1kV/5kHz
Control terminals EN 61000-4-4 2kV/5kHz
Surge
Power terminals EN 61000-4-5 1.2/50 s,
1 kV phase/phase, 2 kV phase/PE
Control terminals EN 61000-4-5 1.2/50 s, 1 kV
Operation on public
supply systems
EN 61000-3-2
EN 61000-3-12
The devices are intended for use in an industrial
environment. When being u sed on public network, additional
measures must be taken to limit the expected radio
interference. The compliance with the requirements for the
machine/plant is t he responsibility of the manufacturer of
the machine or system!
Voltage deviations
Voltage dips EN 61800-3 Short mains voltage dips (comp. IEC 61000-2-1) can lead to a
switch-off of the motor.
