Technical data
Rated data
Overview
4

32
EDS84DG752 EN 5.0
Power losses
Power loss P
V
[W]
Type when operating with rated output current I
arated
when controller is inhibited
E84DGDVB3714 26 9
E84DGDVB5514 33 9
E84DGDVB7514 41 9
E84DGDVB1124 52 9
E84DGDVB1524 61 9
E84DGDVB2224 88 10
E84DGDVB3024 111 10
E84DGDVB4024 140 11
E84DGDVB5524 185 11
E84DGDVB7524 230 11
