Lenze E84DGDVB7514 User Manual

Technical data
Rated data
Operation at rated mains voltage 400 V
4

34
EDS84DG752 EN 5.0
Fuses and cable cross -sections
ƒ Point-to-point connection - direct wiring of the mains voltage - typical fusing
Operation
Type
Installation according to EN 60204-1
1)
Installation according
to UL
2)
FI
3)
  L1, L2, L3 - laying system  L1, L2, L3
B2 C F
[A] [A] [mm
2
] [mm
2
] [mm
2
] [A] [AWG] [mA]
E84DGDVB3714 C 16 16 2.5 - - 15 12  30
E84DGDVB5514 C16 16 2.5 - - 15 12  30
E84DGDVB7514 C16 16 2.5 - - 15 12  30
E84DGDVB1124 C16 16 2.5 - - 15 12  30
E84DGDVB1524 C16 16 2.5 - - 15 12  30
E84DGDVB2224 C16 16 2.5 - - 15 12  300
E84DGDVB3024 C16 16 2.5 - - 15 12  300
E84DGDVB4024 C20 20 4.0 - - 20 12  300
E84DGDVB5524 C20 20 4.0 - - 20 12  300
E84DGDVB7524 C20 20 4.0 - - 20 12  300
ƒ Multiple connection - loop-through connection of the mains voltage - maximum
fusing
Operation
Type
Installation according to EN 60204-1
1)
Installation according
to UL
2)
FI
3)
  L1, L2, L3 - laying system  L1, L2, L3
B2 C F
[A] [A] [mm
2
] [mm
2
] [mm
2
] [A] [AWG] [mA]
E84DGDVB3714 C 32 32 6.0 - - 15 12  30
E84DGDVB5514 C32 32 6.0 - - 15 12  30
E84DGDVB7514 C32 32 6.0 - - 15 12  30
E84DGDVB1124 C32 32 6.0 - - 15 12  30
E84DGDVB1524 C32 32 6.0 - - 15 12  30
E84DGDVB2224 C32 32 6.0 - - 25 10  300
E84DGDVB3024 C32 32 6.0 - - 25 10  300
E84DGDVB4024 C50 50 16.0 - - 50 6  300
E84DGDVB5524 C50 50 16.0 - - 50 6  300
E84DGDVB7524 C50 50 16.0 - - 50 6  300
1)
These values are recommendations only. Other dimensioning values/laying systems are possible (e.g. according to
VDE 0298-4). The cable cross-sections apply under the following conditions: Use of PVC-insulated copper cables,
conductor temperature < 70 °C, ambient temperature < 45°C, no bundling of cables or cores, three loaded cores.
2)
Only use UL-approved cables, fuses and fuse holders.
UL fuse: voltage  500 V, tripping characteristic e.g. ”CC”. The cable cross-sections apply under the following
conditions: conductor temperature < 75 °C, ambient temperature < 45°C.
3)
Universal-current sensitive earth-leakage circuit breaker, short-time delayed
 Circuit breaker
 Fuse of gG/gL utilisation category or semiconductor fuses of gRL utilisation category
 Fuse
Observe national and regional regulations
