Lenze E84DGDVB7514 User Manual

Technical data
Rated data
Operation at increased rated power at 400 V mains voltage
4

36
EDS84DG752 EN 5.0
Switching frequency-dependent output currents
Output currents [A] at switching frequency
2kHz 4kHz 8kHz 16 kHz
Type I
arated2
I
aM2
I
arated4
I
aM4
I
arated8
I
aM8
I
arated16
I
aM16
E84DGDVB3714 - - 1.6 2.6 - - - -
E84DGDVB5514 - - 2.2 3.6 - - - -
E84DGDVB7514 - - 2.9 4.8 - - - -
E84DGDVB1124 - - 3.8 6.4 - - - -
E84DGDVB1524
1)
- - 4.7 7.8 - - - -
E84DGDVB2224 - - 6.7 11.2 - - - -
E84DGDVB3024
1)
- - 8.7 14.6 - - - -
E84DGDVB4024 - - 11.4 19.0 - - - -
E84DGDVB5524 - - 15.6 26.0 - - - -
E84DGDVB7524 - - 19.8 33.0 - - - -
I
aNx
Rated value of continuous output current
I
aMx
Maximum output current (overload current)
 Periodic load change of 3 s with I
aMx
and recovery time of 12 s according to
the t ables under chapter  4.4
1) Operation with an increased rated power only for motor mounting.
Fuses and cable cross -sections
The data/recommendations for o peration on a rated mains voltage 400 V can be applied.
( 34)
