Technical data
Overcurrent operation
4

41
EDS84DG752 EN 5.0
Type
I
amax
/I
aN8
[%] in 15-s cycle 
f=2kHz f=4kHz f=8kHz f = 16 kHz
       
E84DGDVB3714
-
- 200 75 200 75 120 50
E84DGDVB5514
E84DGDVB7514
E84DGDVB1124
E84DGDVB1524
E84DGDVB2224
E84DGDVB3024
E84DGDVB4024
E84DGDVB5524
E84DGDVB7524
Type
I
amax
/I
aN8
[%] in 180-s cycle 
f=2kHz f=4kHz f=8kHz f = 16 kHz
       
E84DGDVB3714
-
- 150 75 150 75 100 50
E84DGDVB5514
E84DGDVB7514
E84DGDVB1124
E84DGDVB1524
E84DGDVB2224
E84DGDVB3024
E84DGDVB4024
E84DGDVB5524
E84DGDVB7524
 Tip!
For calculations of application-specific cycles please contact your Lenze contact
person.
