Product description
Features and variants
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
3.2 Features and variants
The AS-Interface Communication Unit is available in the following versions:
• The AS-Interface Communication Unit is ...
• mounted on top of the Wiring Unit (E84DGVNxx);
• supplied internally by the Drive Unit (E84DGDVxxxxxxxx) and externally by the AS-i bus.
• The I/O connections can be brought into the device via M12 connectors or cable glands.
• Devices without an integrated safety system (safety option) have no analog input and no relay
output.
• The integrated safety system can be used on machines for the protection of persons.
• The Communication Unit AS-Interface supports the services of the AS-i version 3.0:
• cyclic reading and writing of single parameters
•cyclic drive control
• acyclic reading and writing of parameter sets
• acyclic query of diagnostic data
• Two AS-i slaves are contained in the Communication Unit. Thus, two AS-i addresses are
assigned. AS-i concept of the Communication Unit
( 34)
• The acyclic communication via the AS-i bus and the slave 2 are available for the read and write
access to parameters.
• The AS-i slaves can be addressed ...
• via a programming unit or from the master or
• by means of parameters (e.g. via »Engineer«, keypad or EPM).
• The AS-i slaves must be parameterised via the Lenze »Engineer« (e.g. parameterisation of the
brake or bit interconnection for control via the AS-i master).
• Up to 31 standard slaves can be connected to an AS-i network. In this case the max. cycle time
is 5 ms. Up to 62 so-called A/B slaves can be connected if extended addressing is used. In this
case the max. cycle time is 10 ms.
Product series Type designation Product features
Enclosure Connection AS-Interface I/O: Connection via terminal I/O: Connection via M12 Safety
Inverter Drives 8400 motec
Communication Unit AS-Interface
E84DGFCAFNP IP 65 M12 3× DI
1× DO
2× DI
E84DGFCAENP IP 65 M12 2× DI 3× DI
1× DO
E84DGFCAFJP IP 65 M12 3× DI
1× DO
1× AI
2× DI 
E84DGFCAEJP IP 65 M12 3× DI 2× DI
1× DO
1× AI

