1.2 Conventions used
This documentation uses the following conventions to distinguish between different types of
information:
Type of information Highlighting Examples/notes
Spelling of numbers
Decimal Normal spelling Example: 1234
Decimal separator Point The decimal point is always used.
For example: 1234.56
Hexadecimal 0x[0 ... 9, A ... F] Example: 0x60F4
Binary
• Nibble
0b[0, 1] Example: ’0b0110’
Example: ’0b0110.0100’
Text
Program name » « PC software
Example: Lenze »Engineer«
Control element Bold The OK button... / The Copy command... / The
Properties tab... / The Name input field...
Hyperlink underlined
Optically highlighted reference to another topic. Can
be activated with a mouse-click in this
documentation.
Icons
Page reference ( 7) Optically highlighted reference to another page. Can
be activated with a mouse-click in this
documentation.
Step-by-step instructions

Step-by-step instructions are indicated by a
pictograph.
