Lenze ECSEM Series User Manual

Commissioning
Operation with motors from other manufacturers
Entering motor data manually
6

175
EDBCSXM064 EN 11.0
IMPORTANTPossible settingsCode
SelectionLenze/
{Appl.}
DesignationNo.
C0058 Rotor diff −90.0
Rotor displacement angle (offset
angle)
Input in case of Lenze motor with
l resolver: −90°
l hiperface absolute value
encoder: 0°
Code value is adapted by the
rotor position adjustment
function (C0095).
Only relevant for the operation
of synchronous motors.
 180
−180.0 {0.1 _} 179.9
[C0080] Res pole no. 1
Number of pole pairs of resolver
1 {1} 10
[C0081] Mot power 3.20
Rated motor power according to
nameplate
0.01 {0.01 kW} 500.00
[C0082] DIS:Rr
Rotor resistance of the
asynchronous motor
Read only
0.000 {0.001 W} 32.767
[C0084] Mot Rs 1.10
Stator resistance of the motor
The upper limit is
device−dependent.
0.00 {0.01 W} 95.44 ECSxS/P/M/A004
47.72 ECSxS/P/M/A008
23.86 ECSxS/P/M/A016
11.93 ECSxS/P/M/A032
7.95 ECSxS/P/M/A048
5.96 ECSxS/P/M/A064
[C0085] Mot Ls 5.30
Leakage inductance of the motor
0.00 {0.01 mH} 200.00
[C0087] Mot speed 3700
Rated motor speed
300 {1 rpm} 16000
[C0088] Mot current 7.0
Rated motor current
0.5 {0.1 A} 500.0
[C0089] Mot
frequency
185
Rated motor frequency
10 {1 Hz} 1000
[C0090] Mot voltage 325
Rated motor voltage
50 {1 V} 500
[C0091] Mot cos phi 1.0
cos j of the asynchronous motor
0.50 {0.01} 1.00
[C0095] Rotor pos adj 0
Activation of rotor position
adjustment for automatic
determination of the rotor
displacement angle.
C0058 displays the determined
rotor displacement angle (offset
angle).
 180
0 Inactive
1 Active
