Monitoring functions
Overview of monitoring functions
9
224
EDBCSXM064 EN 11.0
Possible fault responses
l Lenze setting
ü Can be set
Monitoring
OffFail−QSPWarningMessageTRIPCode
SourceDescriptionFault message
0072 PR1 Check sum error in parameter set 1 Internal l
0074 PEr Program error Internal l
0075 PR0 Error in the parameter sets Internal l
0079 PI Error during parameter initialisation Internal l
0080 PR6 l For ECSxS/P/M:Internal fault
l For ECSxA: Too many user codes
Internal l
Application−specific fault messages
x400 Pos HW End Positive hardware limit switch has bee approached. C3175 ü ü ü l
x401 Neg HW
End
Negative hardware limit switch has been approached. C3175 ü ü ü l
x404 Follow Err 1 Warning against exceeding the following error limit (C3030). C3032 ü ü l ü ü
x405 Follow Err 2 Following error limit (C3031) has been exceeded. C3033 ü ü ü l ü
x406 Home Pos
Err
Home position is unknown. C3170 ü ü ü ü l
x407 Toggle Bit
Err
Toggle bit error C3160 ü ü ü l ü
3408 External
QSP
Externally enabled quick stop (QSP) via X6/DI1
(A reset of the fault message is required.)
l
x410 VelModeErr Speed error in "Velocity Mode" (C5000 = 2) C3038 ü ü ü ü l
x: 0 = TRIP, 1 = message, 2 = warning, 3 = FAIL−QSP
1)
Adjustable in the DDS under Project Exceptional handling
2)
For ECSxA... only
