14 Implemented CIP™ objects
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
General class attributes
Attribute
ID
Service Name Data type Description
1 Get Revision UINT Revision no. of the object
2 Get Max. Instance UINT Max. number of instances of the object
3 Get Number of Instances UINT Number of instances of the object
4 Get Optional Attribute List: STRUCT of: List of the optional instance attributes:
Number Attributes UINT Number of optional attributes
Optional Attributes ARRAY of UINT Listing of the optional attributes
5 Get Optional Service List: STRUCT of: List of the optional services:
Number Services UINT Number of optional services
Optional Services ARRAY of UINT Listing of the optional services
6 Get Max. ID Number Class
Attributes
UINT The attribute ID of the last class attribute of
the class description implemented in the
device
7 Get Max. ID Number Instance
Attributes
UINT The attribute ID of the last instance attribute
of the class description implemented in the
device
